SPECIFICATIONS

• Color: Black
• DAC Chipset: MS8412
• USB Chipset: SA9023
• Headphone Chipset: 97220
• Operational Amplifier (OPM) Chipset: NE5532
• PC-USB Input Sampling Rate: 96K/24Bit
• Fiber/Coaxial Input Sampling Rate: 192K/24Bit
• High/Low Sound Adjustment Range: ±6 dB
• Frequency Response: 20 Hz - 20 kHz (±3 dB)
• Supported Operating Systems for PC-USB: XP, W7, W8, W10, MAC, Linux
• Total Harmonic Distortion (THD): 0.01%
• Signal-to-Noise Ratio (SNR): ≥ 105 dB
• Amplifier Output Maximum Power: 125 mW (32Ω load)
• Headphone Matching Impedance: 16-200Ω
• Working Voltage: DC 5V
• RCA Output Level: 2.3V
• Dimensions (L x W x H): 73.5 x 98 x 33 mm (without knobs and terminals)
